Engranaje planetarioa 36 mm

As the professional manufacture, we would like to provide you Ruixing Planetary Gearhead 36mm. And we will offer you the best after-sale service and timely delivery. The 36mm planetary gearhead, in particular, is often used in applications that require a high output torque, such as:Industrial automation, Material handling, Printing machinery, Food processing equipment, Packaging machinery. In these applications, the 36mm planetary gearhead can provide precise motion control and increased torque output, improving the efficiency and reliability of the machinery.

Parametro teknikoa
Engranaje-kutxaren diametroa		mm		36
Ardatzaren errodamendua		aukerakoa/-		Bola-errodamendua
Garbitasun erradiala		mm		≤0,1
Garbiketa axiala		mm		≤0,2
Baimen Sarrera Abiadura		rpm		≤10.000
Gomendatutako Tenperatura Tartea		℃		-20tik +125era
Baimena Instalatzeko Indarra		N		≤120
Karga Axiala		N		≤80
Karga erradiala		N		≤100
Aplikazio tipikoak
Gailu medikoa		Produktu digitalak		UAV		Automatizazio industriala
produktuaren informazioa
1		Etapa	1	2	3		4		5
2		Eskaera kopurua	1236002	1236010	1236035	1236073	1236097	1236159	1236274	1236402
3		Ratioa	3.75	14.06	52.73	141.56	197.75	474.27	114.844	3082.77
4		Eskaera kopurua	1236004	1236014	1236042	1236077	1236109	1236182	1236303	1236432
5		Ratioa	4.67	17.50	65.63	169.00	246.09	660.59	1429.17	4293.85
6		Eskaera kopurua	1236006	1236019	1236051		1236124	1236198	1236333	1236449
7		Ratioa	6.50	21.78	81.67		306.25	920.11	1778.52	5980.72
8		Eskaera kopurua		1236024	1236061		1236142		1236362
9		Ratioa		30.33	101.63		381.11		2213.27
1		L (mm)	36	43.3	50.6		57.9		65.2
2		Momentua (Nm)	4.0	8.0	16.0		16.0		20
3		Geltoki Torque(Nm)	5.0	12.0	25.0		25.0		30
4		Gehienezko eraginkortasuna (%)	90	81	73		65		59
5		Pisua (g)	210	245	280		315		350
6		Kargarik gabeko erreakzioa (°)	0.8	1.0	1.0		1.0		1.2
